HIGH TEMPERATURE HEAT TREATMENT FURNACE MSW-253
This is a small description
features
- Most useful where high temperature curing is required with maximum temperature upto 1450°C OR 1700°C and working temperature range upto 1400°C OR 1600°C.
- Fitted with Microprocessor Based Digital Temperature Indicator-cum-controller.
- Silicon-carbide heating elements are fitted for uniform temperature inside the chamber.
- Body mounted on a heavy M.S. frame covered with CRC Sheet duly powder coated.
- Fitted with chamber made of CUMILAG tiles exhibit unique combination of chemical, mechanical stability and insulating properties.
- These are suitable for applications at high service temperatures.
- Bubble alumina range of insulating refractories are of light weight, have good load bearing capacity, and low heat capacity.
- These can be directly exposed to flame, and combustion products.
- Our furnaces have some very unique features:-
- * Very high refractoriness, structural strength
- * Low thermal conductivity, shrinkage and creep.
- High resistance to reducing atmosphere and Uniform pore size.
- Distribution and Control through a phase angle control THYRIOSTORISED POWER DRIVE with Soft Start in lieu of Manual Control System, and a multitap solid state step down transformer.
| Technical Specifications & Ordering Informations | |||||||||||||||||||||||||||||||
| WITH WORKING TEMPERATURE 1400°C | |||||||||||||||||||||||||||||||
| MODEL | #HTMF-253(MP) | #HTMF-253(24) | #HTMF-253(28) | ||||||||||||||||||||||||||||
| CAPACITY | 7 Ltrs. | 24 Ltrs. | 28 Ltrs. | ||||||||||||||||||||||||||||
| HEATING CHAMBER (WXHXD) | 150 x 150 x 300 mm | 200 x 200 x 600 mm | 300 x 300 x 300 mm | ||||||||||||||||||||||||||||
| THYRISTON POWER DRIVE | Phase Angle control Thyristor Power drive. Along with voltage/current control and limit facility. | ||||||||||||||||||||||||||||||
| TEMPERATURE CONTROLLER CUM INDICATOR | Microprocessor Digital PID Temperature Indicator-cum-Controller | ||||||||||||||||||||||||||||||
| TEMPERATURE RANGE | 1450⁰C Maximum, Working Upto 1400°C | ||||||||||||||||||||||||||||||
| THERMOCOUPLE | Input Sensor:- Pt.Pt./Rh 30% Type “R” with Recrystalized alumina sheath & connecting holder complete set. | ||||||||||||||||||||||||||||||
| THERMAL INSULATION | |||||||||||||||||||||||||||||||
| CONSTRUCTION | (Floor Model Type) Rugged body; height of the door from the floor is approx 4.5 feet with steel stand. Swing aside door, manually operated front side of the furnace | ||||||||||||||||||||||||||||||
| COOLING FAN/AIR CIRCULATION | Attached with Furnace, Provided inside the control unit to protect COSTLY COMPONENT | ||||||||||||||||||||||||||||||
| ELECTRIC SUPPLY | Input Supply 230V AC, 50Hz | ||||||||||||||||||||||||||||||
| WITH WORKING TEMPERATURE 1600°C | |||||||||||||||||||||||||||||||
| MODEL | #HTMF-253(UHT) | ||||||||||||||||||||||||||||||
| CAPACITY | 7 Ltrs. | ||||||||||||||||||||||||||||||
| HEATING CHAMBER (WXHXD) | 150 x 150 x 300 mm | ||||||||||||||||||||||||||||||
| THYRISTON POWER DRIVE | Phase Angle control Thyristor Power drive. Along with voltage/current control and limit facility. | ||||||||||||||||||||||||||||||
| TEMPERATURE CONTROLLER CUM INDICATOR | Microprocessor Digital PID Temperature Indicator-cum-Controller | ||||||||||||||||||||||||||||||
| TEMPERATURE RANGE | 1700⁰C Maximum, Working Upto 1600°C | ||||||||||||||||||||||||||||||
| THERMOCOUPLE | Input Sensor:- Pt.Pt./Rh 30% Type “R” with Recrystalized alumina sheath & connecting holder complete set. | ||||||||||||||||||||||||||||||
| THERMAL INSULATION | SUPER REFRACTORY and FIBROUS CERAMIC of appropriate grade and low heat capacity | ||||||||||||||||||||||||||||||
| CONSTRUCTION | (Floor Model Type) Rugged body; height of the door from the floor is approx 4.5 feet with steel stand. Swing aside door, manually operated front side of the furnace | ||||||||||||||||||||||||||||||
| COOLING FAN/AIR CIRCULATION | Attached with Furnace, Provided inside the control unit to protect COSTLY COMPONENT | ||||||||||||||||||||||||||||||
| ELECTRIC SUPPLY | Input Supply 230V AC, 50Hz | ||||||||||||||||||||||||||||||
options
- Profile controller with ramp and soak profiles with multiple programmes and steps, in lieu of standard controller to cost extra.
- With TFT Touch Screen Display Controller, in lieu of standard controller to cost extra.
- Spare Silicon Carbide Heating rod to cost extra.
- Spare Clip to hold heating rod.
