applications
- Designed for controlling above ambient temperatures in external instrumentation or for immersion applications. A very handy tool for general lab requirements and applications.
advantages & benefits
- Compact space saving concept can be placed under or over the workbench.
- Effective water/liquid heated circulator for tighter controls.
- Reduces tap water consumption thus reducing high cost of water and waste water.
- Waste water does not contain hazardous substances thus eliminating danger to personnel and environment caused by solvents.
- Builts in circulator pump for efficient circulating processes. Offers highest level of performance, flexibility and control for most demanding applications.
- Industrial grade energy efficient heaters reduces power bills drastically.
- Fitted with Microprocessor based Digital temperature Indicator-Cum-Controller, to control temperature range from Ambient +5°C to 90°C.
- Low noise level.
constructional features
- MOC (Outer) : CRC Sheet duly powder coated
- MOC (Inner Chamber & Lid) : Stainless Steel Sheet (S.S.-304 Grade)
- Insulation : Filled with high grade mineral wool
- Display : LED display for set value (SV) & process value (PV)
- Temperature Accuracy : ±0.5°C.
- Temperature Display Resolution : 0.1°C.
- Circulating Pump : Powerful pump with 15 Lpm capacity at zero head (for water)
- Silicon Tubing : Supplied with 2 No. of rubber tube of 1 mtr each as standard accessory
- Advisable : Do not use water above 90°C (use silicon oils above 90°C)
- Work on : 220/230 Volts, 50/60 AC supply.
| Technical Specifications & Ordering Informations | |||
| PRODUCT CODE | INTERNAL DIMENSIONS | CAPACITY | TEMPERATURE RANGE |
|---|---|---|---|
| #ARBR-5* | 295x146x150 | 5 ltrs. | Upto 70°C |
| #HWBC-13 | 325x295x150 | 13 ltrs. | Upto 70°C |
| #HWBC-17 | 325x295x200 | 17 ltrs. | Upto 70°C |
| #HWBC-13(HT) | 325x295x150 | 13 ltrs. | Upto 90°C |
| #HWBC-17(HT) | 325x295x200 | 17 ltrs. | Upto 90°C |
- *Specially designed for Abbe and Butyro Refractometer
